起源の場所:
中国湖南
ブランド名:
PisenEner
証明:
CE/ROHS/MSDS/UN38.3 etc
モデル番号:
pe48100
文書:
| Model No | PE48050 | PE48100 | PE48150 | PE48200 | PE48250 |
|---|---|---|---|---|---|
| Voltage | 48 V | 48 V | 48 V | 48 V | 48 V |
| Capacity | 50Ah | 100Ah | 150Ah | 200Ah | 250Ah |
| Energy | 2.4KWH | 5.12KWH | 7.68KWH | 10.24KWH | 12.80KWH |
| Operation voltage | 35.25-54.75 Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc |
| Max.charging voltage | 54.75Vdc | 58.4 Vdc | 58.4 Vdc | 58.4 Vdc | 58.4 Vdc |
| Max.charging and discharging current | 50A | 100A | 100A | 100A | 100A |
| Max Power | 2400W | 5120W | 7680W | 10240W | 12800W |
| Life time(25°C) | 10 years | ||||
| Life cycles(80% DOD, 25°C) | >6000 Cycles | ||||
| Storage time / temperature | 5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C | ||||
| Operation temperature | -20°C to 60°C @60+/-25% Relative Humidity | ||||
| Storage temperature | 0°C to 45°C @60+/-25% Relative Humidity | ||||
| Lithium Battery Standard | UL1642, IEC62619, UN38.3, ROHS,CE-EMC | ||||
| Enclosure protection rating | IP65 | ||||
| Dimensions(L×W×H)mm | 482*410*89 | 482*400*177 | 482*430*222 | 482*500*280 | 482*500*280 |
| Weight | 24KG | 43KG | 65KG | 82KG | 100KG |
Hunan Pinsheng Energy Technology Co.,LTD located in Changsha City, Hunan Province, We focus on developing and producing Li-ionbattery and battery system integration, through many years development and research.we have formed a complete industry chain from research, production to sales.
Our lithium ion battery has the characteristics of longer recycle life, more higher security and more reliability, higher energy density and other superior performance.products are widely used in electric bikes, E-scooter, electric motorcycles, electric tricycles, golf cart, fork lift, electric vehicles, UPS, telecommunication system, off grid wind & solar energy storage and etc.
Pinsheng Energy Battery products sell well at home and abroad, we has strict quality guarantee system to ensure high-quality products. We put customers' needs at the first and listen to their suggestions.We continuously improve our product quality and services. We have our own R&D team so customized products are fine for us, Pinsheng Energy has now became a competetive manufacturer in China, we are edicated to be a top OEM & ODM manufacturer in China.
