起源の場所:
中国湖南
ブランド名:
PisenEner
証明:
CE/ROHS/MSDS/UN38.3 etc
モデル番号:
pe48100
文書:
| Model No | PE48050 | PE48100 | PE48150 | PE48200 | PE48250 |
|---|---|---|---|---|---|
| Voltage | 48 V | 48 V | 48 V | 48 V | 48 V |
| Capacity | 50Ah | 100Ah | 150Ah | 200Ah | 250Ah |
| Energy | 2.4KWH | 5.12KWH | 7.68KWH | 10.24KWH | 12.80KWH |
| Operation voltage | 35.25-54.75 Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc |
| Max.charging voltage | 54.75Vdc | 58.4 Vdc | 58.4 Vdc | 58.4 Vdc | 58.4 Vdc |
| Max.charging and discharging current | 50A | 100A | 100A | 100A | 100A |
| Max Power | 2400W | 5120W | 7680W | 10240W | 12800W |
| Life time(25°C) | 10 years | ||||
| Life cycles(80% DOD, 25°C) | >6000 Cycles | ||||
| Storage time / temperature | 5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C | ||||
| Operation temperature | -20°C to 60°C @60+/-25% Relative Humidity | ||||
| Storage temperature | 0°C to 45°C @60+/-25% Relative Humidity | ||||
| Lithium Battery Standard | UL1642, IEC62619, UN38.3, ROHS,CE-EMC | ||||
| Enclosure protection rating | IP65 | ||||
| Dimensions(L×W×H)mm | 482*410*89 | 482*400*177 | 482*430*222 | 482*500*280 | 482*500*280 |
| Weight | 24KG | 43KG | 65KG | 82KG | 100KG |
